F6

The F6 is a 5-spoke "fan plate" with 6" wide spokes. Fan plates are used to connect the bottom tie beam of a truss to two struts and a king post. 6" wide plates look good on timbers ranging in width from 6" to 12". 3/16" steel is a good choice for purely decorative plates. 1/4" is better for applications that need structural support.

Click image for zoomed in view with dimensions.

Please select the plate pitch and thickness below
Black powder coating can be added at checkout.

$ 84.00
