Tie beam to two struts

Cornice collection U3

$76.00

  • Ships free in the lower 48 states.
  • 5% off orders over $2,000, 10% off over $5,000. No code needed.
U3: the shop drawing from its cutting file, u3.dxf, with its dimensions

Thickness

3/16" Decorative $76 1/4" Structural $101

3/16" steel is a good choice for purely decorative plates. 1/4" is better for applications that need structural support.

01 Description

About the U3

The U3 is a 4-spoke "fan plate" with 3" wide spokes. U fan plates are used to connect the bottom tie beam of a truss to two struts without a middle king post.

02 In a truss

Where it goes

The U3 on a truss drawn from the cutting files, marked in red.

Cornice truss with struts, no king post, with the U3 marked
See every Cornice plate in a truss
